The life of lift chains on lift trucks can be lengthened greatly with correct maintenance and care. For example, right lubrication is actually the most effectual technique to be able to lengthen the service capability of this particular component. It is really important to apply oil occasionally making use of a brush or other lube application tool. The volume and frequency of oil application should be sufficient so as to stop whichever rust discoloration of oil within the joints. This reddish brown discoloration generally signals that the lift chains have not been properly lubricated. If this particular situation has happened, it is very important to lubricate the lift chains immediately.
During lift chain operation it is common for some metal to metal contact to happen which could cause some components to wear out in the long run. Once there is 3% elongation on the lift chain, it is considered by industry standards to have worn out the chain. To be able to avoid the scary possibility of a catastrophic lift chain failure from occurring, the maker very much recommends that the lift chain be replaced before it reaches three percent elongation. The lift chain lengthens due to progressive joint wear that elongates the chain pitch. This elongation can be measured by placing a certain number of pitches under tension.
So as to ensure correct lift chain maintenance, one more factor to consider is to check the clevis pins on the lift chain for signs of wearing. Lift chains are put together so that the clevis pins have their tapered faces lined up with each other. Usually, rotation of the clevis pins is often caused by shock loading. Shock loading takes place when the chain is loose and then suddenly a load is applied. This causes the chain to experience a shock as it 'snaps' under the load tension. Without the good lubrication, in this case, the pins could rotate in the chain's link. If this situation occurs, the lift chains need to be replaced at once. It is very important to always replace the lift chains in pairs to ensure even wear.
